High-Density MPO Patch Panel with 12F Fiber Counts and Customizable Options for Data Centers
Ürün ayrıntıları:
| Menşe yeri: | Guangdong, SHENZHEN |
| Marka adı: | TAKFLY |
| Sertifika: | CE,ROHS,REACH,ISO9001,ISO14001 |
| Model numarası: | DF-Kaset-T1771 |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 resim |
|---|---|
| Fiyat: | US$0.01 ~ US$1200/PC |
| Ambalaj bilgileri: | sünger + kutu + karton |
| Teslim süresi: | 3-7 iş günü |
| Ödeme koşulları: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
|
Detay Bilgi |
|||
| Dayanıklılıktabanlanabilirlik: | ≤ 0,1dB | Lif Sayıları: | 12F |
|---|---|---|---|
| Adaptör Tipi: | LC Dubleks / SC Simpleks | Diğer Fanout Yolu: | MTP, LC mevcut |
| Fiber Uyumluluğu: | Çoklu mod; Tekli mod | Özelleştirilebilir: | Evet |
| Bağlayıcı Arayüzü: | LC | Hs Kodu: | 854470000 |
| Parlatma: | PC, UPC, APC | Konektör Polaritesi: | A Tipi/B Tipi/C Tipi |
| Fiber Modu: | Çoklu mod | Dış Kılıf Rengi: | Sarı, Aqua veya Özelleştirilmiş |
| Derinlik: | 200 mm | Çalışma Sıcaklığı: | -40°C ile +80°C arası |
| Koparma Uzunluğu: | 0.5M / 1M /1.5M / Özelleştirilmiş | ||
| Vurgulamak: | High-Density MPO Patch Panel,12F Fiber Counts MPO Patch Panel,Customizable MPO Patch Panel |
||
Ürün Açıklaması
Description:
To address the challenges of maximizing cabinet space in modern data centers, we proudly present our Takfly High-Density Rackmount Cabling Solution. This integrated system streamulates fiber management and connection, enabling a clean, scalable, and efficient infrastructure.
Our core solution features a series of rackmounted fiber distribution boxes in 1U, 2U, and 4U configurations. Designed to house and manage our easy-plug, pre-terminated MTP/MPO fiber modules, these enclosures facilitate a true plug-and-play deployment.
We offer complete compatibility with supporting modules and accessories to build a flexible network backbone:
-
MPO-to-LC Cassette Modules (12-fiber & 8-fiber configurations)
-
4-Port MPO Adapter Panels
Each easy-plug MTP/MPO to LC cassette module accommodates a 12-fiber trunk cable and comes pre-loaded with LC adapters. This modular design simplifies installation, reduces on-site termination errors, and allows for easy reconfiguration or expansion.
The Takfly series is engineered for superior network availability and performance, making it the ideal structured cabling foundation for demanding SAN, LAN, and Data Center applications. Optimize your space and simplify your fiber management today.
Features:
- Apply to Main Distribution Area, Horizontal Distribution Area(HDA), Equipment Distribution Area(EDA) cabling systems to meet the cabling requirements of 10G/40G/100G.
- Rack-type shell, with the functions of protecting, managing and organizing optical cables.
- Meet high-density wiring requirements, 1U supports 144 cores, 2U supports 288 cores, 4U supports 576 cores.
- Modular installation method is adopted inside, which avoids welding and improves wiring efficiency.
- The box structure is a sliding rail design, extending straight and smoothly.
- Using three layers of trays, each layer can be placed 4 sets of module boxes or MPO adapter panels, a total of 12 sets of three layers.
Applications:
- Data center
- Telecommunication networks
Standard:
- TIA/EIA-568
- RoHS
- ISO9001
Specifications:
| Size | 482.6mm*464.9mm*44.2mm(1U) |
| Material | SPCC, 1.2mm Black (RAL9005) |
| Weight | 6.8KG |
Structure:
